View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | TO-252 |
| Other | |
| Ciss (pF) | 2900 |
| Compliance | Automotive,RoHS,Halogen Free |
| Crss (pF) | 40 |
| ESD Diode | NO |
| Id (A) | 108 |
| Pd (W) | 125 |
| Qgd (nC) | 17 |
| Qg (nC) | 60 |
| Qgs (nC) | 10 |
| Rds(on) mΩ(max) @Vgs=10V | 6 |
| Rds(on) mΩ(max) @Vgs=4.5V | 9.5 |
| Rds(on) mΩ(typ) @Vgs=10V | 5.2 |
| Rds(on) mΩ(typ) @Vgs=4.5V | 8 |
| Technology | SGT |
| Type | N |
| Vds (V) | 100 |
| Vgs(th) max(V) | 2.5 |
| Vgs (V) | ±20 |
