View full reportTechnical parameters
| Power | |
|---|---|
| Electrical / Current(Max) | 1.5A |
| Electrical / Voltage(Max) | 30V |
| Electrical / Withstanding Voltage | 800V AC r.m.s |
| Environment and package | |
| Compliance / REACH (EU REACH Regulation) | Does not contain REACH SVHC (1907/2006/EC) |
| Compliance / ROHS (EU ROHS Directive) | Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2) |
| Electrical / Operating Temperature Range | -40ºC~+105ºC |
| Mechanical / Mounting Thread | M16x1.5 |
| Mechanical / Panel Mount Feature | Front nut |
| Other | |
| Category / Cable Length(mm) | L=250mm |
| Category / Coding | A-coded |
| Category / Colour | Black |
| Category / Contacts Type | socket |
| Category / Gender | Female |
| Category / Number of Positions | 12Circuits |
| Category / Product Catalog | Connectors |
| Category / Product System | M12 Circular Connector |
| Category / Shielded | Non-shielded |
| Category / Style | Cable assembly |
| Compliance / ELV (EU ELV Directive) | Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements |
| Electrical / Contact Resistance | 5 mΩ Max |
| Electrical / Insulation Resistance | 100 MΩ Min |
| Material / Flammability Rating | UL94 V-0 |
| Material / Locking Material | Metal |
| Material / Material-Contact | Copper alloy |
| Material / Material of Housing | Metal |
| Material / Material-Resin | PA66 |
| Material / Plating | Gold plated |
| Mechanical / Durability (Mating Cycles Max.) | 100 |
| Mechanical / Ingress Protection | IP68 |
| Mechanical / Waterproof / Dustproof | Yes |
| Packaging / Packaging | PE Bag |
