It has a variety of cores and spacing options, covering mainstream market applications and meeting the diverse application needs of users.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Electrical / Current(Max) | 1A |
| Electrical / Voltage(Max) | 250V |
| Electrical / Withstanding Voltage | 500V AC r.m.s |
| Environment and package | |
| Category / Height(mm) | H4.5 |
| Compliance / REACH (EU REACH Regulation) | Does not contain REACH SVHC (1907/2006/EC) |
| Compliance / ROHS (EU ROHS Directive) | Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2) |
| Electrical / Operating Temperature Range | -40ºC~+85ºC |
| Mechanical / Mounting Style | SMT |
| Other | |
| Category / Colour | Black |
| Category / Number of Positions | 4Circuits |
| Category / Orientation | Vertical(180°) |
| Category / Peg | Without peg |
| Category / Pitch | 1.27mm |
| Category / Product Catalog | Connectors |
| Category / Product Category | Female Header |
| Category / Product System | Pin Header/Female Header |
| Category / Row Option | Dual row |
| Category / Style | Socket |
| Compliance / ELV (EU ELV Directive) | Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements |
| Electrical / Contact Resistance | 20 mΩ Max |
| Electrical / Insulation Resistance | 1000 MΩ Min |
| Material / Flammability Rating | UL94 V-0 |
| Material / Material-Contact | Phosphor bronze |
| Material / Material-Resin | PA6T |
| Material / Plating | Gold plated |
| Material / Plating Thickness | Gold flash |
| Packaging / Packaging | Reel(With mylar) |
