View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.550A |
| Power (Watts) | 6.6 W |
| Voltage Range | 4.5 ~ 13.8VDC |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 50.5dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 60mm L x 60mm H |
| Other | |
| Air Flow | 43.4 CFM (1.22m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Delta Electronics |
| Packaging | Tray |
| Part Status | Obsolete |
| RPM | 7000 RPM |
| Series | FFB |
| Static Pressure | 0.766 in H2O (190.8 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.234 lb (106.14 g) |
| Width | 38.00mm |
Documents
No documents are linked to this part yet.
