View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.120A |
| Power (Watts) | 1.44 W |
| Voltage Range | - |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 29.4dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 32.4 CFM (0.907m³/min) |
| Approval Agency | CE, cURus, TUV |
| Bearing Type | Sleeve |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Qualtek |
| Packaging | Bulk |
| Part Status | Discontinued at Digi-Key |
| RPM | 2500 RPM |
| Series | FAD1-08025 |
| Static Pressure | 0.102 in H2O (25.5 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.189 lb (85.73 g) |
| Width | 25.00mm |
