View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.070A |
| Power (Watts) | 840 mW |
| Voltage Range | 10.8 ~ 13.2VDC |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 30.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Size / Dimension | Square - 40mm L x 40mm H |
| Other | |
| Air Flow | 7.0 CFM (0.196m³/min) |
| Approval Agency | CE, cURus, TUV |
| Base Product Number | FAD1-04020 |
| Bearing Type | Sleeve |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Qualtek |
| Packaging | Bulk |
| Part Status | Obsolete |
| RPM | 6200 RPM |
| Series | FAD1-04020 |
| Static Pressure | 0.165 in H2O (41.1 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.062 lb (28.12 g) |
| Width | 20.00mm |
