View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.100A |
| Power (Watts) | 8.50W |
| Voltage Range | - |
| Voltage - Rated | 115VAC |
| AC and DC characteristics | |
| Noise | 31.6dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 29.6 CFM (0.829m³/min) |
| Approval Agency | CE, cURus, TUV |
| Base Product Number | FAA1-08038 |
| Bearing Type | Hydrodynamic |
| Fan Type | Tubeaxial |
| Features | - |
| Ingress Protection | - |
| Manufacturer | Qualtek |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Packaging | Bulk |
| Part Status | Active |
| RPM | 2800 RPM |
| Series | FAA1-08038 |
| Static Pressure | 0.166 in H2O (41.3 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.706 lb (320.24 g) |
| Width | 38.00mm |
Documents
No documents are linked to this part yet.
