F20B130051ZA0060
CanthermCanada

F20B130051ZA0060

ActiveTemperature Sensors - Thermostats - Mechanical

THERMOSTAT 130DEG C SPST-NO 2SIP

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current Rating - AC1.6A (250V)
Current Rating - DC-
Environment and package
Mounting TypeThrough Hole
PackageBulk
Package / Case2-SIP, Potted
Reset Temperature212°F(100°C)
Switching Temperature266°F(130°C)
Other
CircuitSPST-NO
MfrCantherm
Product StatusActive
SeriesF20
Switching Cycles7K
Termination StyleWire Leads
Tolerance±9°F (±5°C)

Documents

No documents are linked to this part yet.
