F20B100051ZA0060
CanthermCanada

F20B100051ZA0060

Thermostats - Mechanical

THERMOSTAT 100DEG C SPST-NO 2SIP

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current Rating - AC1.6A (250V)
Current Rating - DC-
Environment and package
Mounting TypeThrough Hole
Package / Case2-SIP, Potted
Reset Temperature158°F (70°C)
Switching Temperature212°F (100°C)
Other
CircuitSPST-NO
ManufacturerCantherm
PackagingBulk
Part StatusActive
SeriesF20
Switching Cycles7K
Termination StyleWire Leads
Tolerance±9°F (±5°C)

Documents

No documents are linked to this part yet.
