View full reportTechnical parameters
| Power | |
|---|---|
| Electrical / Current(Max) | 1A |
| Electrical / Voltage(Max) | 300V |
| Electrical / Withstanding Voltage | 1000V AC r.m.s |
| Environment and package | |
| Compliance / REACH (EU REACH Regulation) | Does not contain REACH SVHC (1907/2006/EC) |
| Compliance / ROHS (EU ROHS Directive) | Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2) |
| Electrical / Operating Temperature Range | -55ºC~+125ºC |
| Mechanical / Mounting Style | Through hole |
| Other | |
| Category / Colour | Green |
| Category / Number of Positions | 4Circuits |
| Category / Orientation | Vertical(180°) |
| Category / Pitch | 2mm |
| Category / Product Catalog | Connectors |
| Category / Product Category | JL4 |
| Category / Product System | Printed Circuit Connector |
| Category / Row Option | Single row |
| Category / Style | Socket |
| Compliance / ELV (EU ELV Directive) | Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements |
| Electrical / Contact Resistance | 12.5 mΩ Max |
| Electrical / Insulation Resistance | 5000 MΩ Min |
| Material / Flammability Rating | UL94 V-0 |
| Material / Material-Contact | Copper alloy |
| Material / Material-Resin | PA66 |
| Material / Plating | Gold plated |
| Material / Plating Thickness | 0.1μm |
| Packaging / Packaging | Tube |
