View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.090A |
| Power (Watts) | 2.16 W |
| Voltage Range | 14 ~ 27.6VDC |
| Voltage - Rated | 24VDC |
| AC and DC characteristics | |
| Noise | 32.5dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 40mm L x 40mm H |
| Other | |
| Air Flow | 10.1 CFM (0.283m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Base Product Number | EFB0424 |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection |
| Ingress Protection | IP55 - Dust Protected, Water Resistant |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Delta Electronics |
| Packaging | Box |
| Part Status | Active |
| RPM | 9000 RPM |
| Series | EFB |
| Static Pressure | 0.416 in H2O (103.6 Pa) |
| Termination | 2 Wire Leads |
| Weight | 0.073 lb (33.11 g) |
| Width | 20.00mm |
