Display VisionsGermany
LCD MOD 80DIG 20X4 TRANSMISV WHT
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Voltage - Supply | 3.3V |
| Environment and package | |
| Character Size | 6.45mm H x 2.37mm W |
| Dot Size | 0.45mm W x 0.78mm H |
| Operating Temperature | -20°C~70°C |
| Package | Bag |
| Other | |
| Background Color | Blue |
| Backlight | LED - White |
| Base Product Number | EADIP203 |
| Character Format | 5 x 8 Dots |
| Display Format | 20 x 4 |
| Display Mode | Transmissive |
| Display Type | STN - Super-Twisted Nematic |
| Interface | Parallel, 8-Bit, SPI |
| Mfr | Display Visions |
| Number of Characters | 80 |
| Outline L x W x H | 75.00mm x 45.80mm x 10.80mm |
| Product Status | Obsolete |
| Series | EA DIP203 |
| Text Color | White |
| Viewing Area | 61.00mm L x 38.00mm W |
