Rohm SemiconductorJapan
PNP DIGITAL TRANSISTOR (WITH BUI
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Collector Cutoff (Max) | - |
| Current - Collector (Ic) (Max) | 100 mA |
| Power - Max | 150 mW |
| AC and DC characteristics | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 10mA, 5V |
| Frequency - Transition | 250 MHz |
| Environment and package | |
| Mounting Type | Surface Mount |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | SC-89, SOT-490 |
| Supplier Device Package | EMT3F (SOT-416FL) |
| Other | |
| Base Product Number | DTA143 |
| Mfr | Rohm Semiconductor |
| Product Status | Not For New Designs |
| Resistor - Base (R1) | 4.7 kOhms |
| Resistor - Emitter Base (R2) | 47 kOhms |
| Series | Automotive, AEC-Q101 |
| Transistor Type | PNP - Pre-Biased |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 250µA, 5mA |
Documents
No documents are linked to this part yet.
