Microchip TechnologyUnited States
MEMS OSC PROG BLANK 10MHZ-170MHZ
All alternatives
View full reportTechnical parameters
Key specs
Frequency10 ~ 170 MHz
Frequency stability25 ppm
Supply voltage2.25 ~ 3.6 V
Output typeCMOS
| Power | |
|---|---|
| Current - Supply (Max) | 35mA |
| Voltage - Supply | 2.25V ~ 3.6V |
| AC and DC characteristics | |
| Available Frequency Range | 10 MHz ~ 170 MHz |
| Frequency Stability | - |
| Frequency Stability (Total) | ±25ppm |
| Spread Spectrum Bandwidth | - |
| Environment and package | |
| Height - Seated (Max) | 0.035" (0.90mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~125°C |
| Package | Tube |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Other | |
| Base Product Number | DSC8121 |
| Base Resonator | MEMS |
| Function | Enable/Disable |
| Mfr | Microchip Technology |
| Output | CMOS |
| Product Status | Active |
| Programmable Type | Blank (User Must Program) |
| Ratings | - |
| Series | DSC8121 |
| Type | XO (Standard) |
