ConesysUnited States
CONN RCPT MALE 28POS GOLD CRIMP
All alternatives
View full reportTechnical parameters
Key specs
Positions28
GenderMale
| Power | |
|---|---|
| Current Rating (Amps) | - |
| Voltage Rating | - |
| Environment and package | |
| Mounting Feature | Flange |
| Mounting Type | Panel Mount |
| Operating Temperature | -65°C ~ 175°C |
| Package | Box |
| Shell Size - Insert | 19-28 |
| Shell Size, MIL | F |
| Other | |
| Applications | Aviation, Marine, Military |
| Backshell Material, Plating | - |
| Base Product Number | D38999/20WF |
| Cable Opening | - |
| Color | Olive Drab |
| Connector Type | Receptacle, Male Pins |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
| Contact Material | Copper Alloy |
| Fastening Type | Threaded |
| Features | - |
| Ingress Protection | Environment Resistant |
| Insert Material | - |
| Material Flammability Rating | - |
| Mfr | Conesys |
| Number of Positions | 28 |
| Orientation | A |
| Primary Material | Metal |
| Product Status | Active |
| Series | Military, MIL-DTL-38999 Series III |
| Shell Finish | Olive Drab Cadmium |
| Shell Material | Aluminum |
| Shielding | Shielded |
| Termination | Crimp |
