CLU024-1204B8-32GV1F6
CitizenJapan

CLU024-1204B8-32GV1F6

ObsoleteLED Lighting - COBs, Engines, Modules, Strips

COB LED VIVID WARM PLUS 1129LM

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current - Max720mA
Current - Test360mA
Lumens/Watt @ Current - Test95 lm/W
Voltage - Forward (Vf) (Typ)35.7V
Environment and package
Height1.40mm
Luminous Flux @ Current/Temperature1225lm(Typ)
PackageTray
Size / Dimension13.50mm L x 13.50mm W
Temperature - Test25°C
Other
Base Product NumberCLU024
CCT (K)-
ColorWhite, Warm
ConfigurationSquare
CRI (Color Rendering Index)95 (Typ)
Features-
Lens TypeFlat
Light Emitting Surface (LES)9.80mm Dia
MfrCitizen
Product StatusObsolete
SeriesCLU024
TypeChip On Board (COB)
Viewing Angle-
Wavelength-

Documents

No documents are linked to this part yet.
