Key specs
Resistance4.7 MΩ
Tolerance5 %
Power250 mW
Temperature coefficient-1.3 kppm/°C
| Power | |
|---|---|
| Power (Watts) | 0.25W, 1/4W |
| Environment and package | |
| Height - Seated (Max) | - |
| Operating Temperature | -55°C ~ 155°C |
| Package / Case | Axial |
| Size / Dimension | 0.091" Dia x 0.240" L (2.30mm x 6.10mm) |
| Supplier Device Package | Axial |
| Temperature Coefficient | 0/ -1300ppm/°C |
| Other | |
| Composition | Carbon Film |
| Failure Rate | - |
| Features | Flame Proof, Safety |
| Mfr | KOA Speer Electronics, Inc. |
| Number of Terminations | 2 |
| Packaging | Bulk |
| Part Status | Active |
| Resistance | 4.7 MOhms |
| Series | CF |
| Tolerance | ±5% |
