Talema Group LLCUnited States
CMC 18MH 600MA 2LN TH
All alternatives
View full reportTechnical parameters
Key specs
Number of lines2
Current rating600 mAMax
DC resistance868 mΩMax
| Power | |
|---|---|
| Current Rating (Max) | 600mA |
| Voltage Rating - AC | 250V |
| Voltage Rating - DC | - |
| AC and DC characteristics | |
| Inductance @ Frequency | 18 mH @ 10 kHz |
| Environment and package | |
| Height (Max) | 0.492" (12.50mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~125°C |
| Package | Tray |
| Package / Case | Horizontal, 4 PC Pin |
| Size / Dimension | 0.689" L x 0.669" W (17.50mm x 17.00mm) |
| Other | |
| Approval Agency | - |
| DC Resistance (DCR) (Max) | 868mOhm |
| Features | - |
| Filter Type | Signal Line |
| Mfr | Talema Group LLC |
| Number of Lines | 2 |
| Product Status | Active |
| Ratings | - |
| Series | CA |
