CAF-0.5-27
Talema Group LLCUnited States

CAF-0.5-27

ActiveCommon Mode Chokes

CMC 27MH 500MA 2LN TH

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Number of lines2
Current rating500 mAMax
DC resistance1.179 ΩMax
Power
Current Rating (Max)500mA
Voltage Rating - AC250V
Voltage Rating - DC-
AC and DC characteristics
Inductance @ Frequency27 mH @ 10 kHz
Environment and package
Height (Max)0.492" (12.50mm)
Mounting TypeThrough Hole
Operating Temperature-40°C~125°C
PackageTray
Package / CaseHorizontal, 4 PC Pin
Size / Dimension0.689" L x 0.669" W (17.50mm x 17.00mm)
Other
Approval Agency-
DC Resistance (DCR) (Max)1.179Ohm
Features-
Filter TypeSignal Line
MfrTalema Group LLC
Number of Lines2
Product StatusActive
Ratings-
SeriesCA
