Bel Fuse Inc.United States
FUSE BRD MNT 2.5A 63VAC/VDC 1206
All alternatives
View full reportTechnical parameters
Key specs
Rated current2.5 A
Rated voltage63 V
Response timeSlow
Breaking capacity50 A
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | 50A |
| Current Rating (Amps) | 2.5 A |
| Voltage Rating - AC | 63 V |
| Voltage Rating - DC | 63 V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~125°C |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension | 0.126" L x 0.062" W x 0.023" H (3.20mm x 1.58mm x 0.58mm) |
| Other | |
| Approval Agency | CE, cURus |
| Color | - |
| DC Cold Resistance | 0.072 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 0.4 |
| Mfr | Bel Fuse Inc. |
| Product Status | Obsolete |
| Response Time | Slow Blow |
| Series | C1S |
