BridgeluxUnited States
FULL FLUX AND FULL VF BINS
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Max | 120mA |
| Current - Test | 65mA |
| Flux @ 25°C, Current - Test | 31lm (Typ) |
| Flux @ 85°C, Current - Test | 27lm (Typ) |
| Lumens/Watt @ Current - Test | 164 lm/W |
| Voltage - Forward (Vf) (Typ) | 2.9V |
| Environment and package | |
| Height - Seated (Max) | 0.031" (0.80mm) |
| Mounting Type | Surface Mount |
| Package | Tape & Reel (TR) |
| Package / Case | 1411 (3528 Metric) |
| Size / Dimension | 0.138" L x 0.110" W (3.50mm x 2.80mm) |
| Supplier Device Package | 1411 |
| Thermal Resistance of Package | 28.6°C/W |
| Other | |
| Base Product Number | BXFN-50 |
| CCT (K) | 5000K 6-Step MacAdam Ellipse |
| Color | White, Cool |
| CRI (Color Rendering Index) | 88 |
| Mfr | Bridgelux |
| Product Status | Active |
| Series | F90 |
| Viewing Angle | 120° |
