Ampleon USA Inc.Netherlands
RF FET 2 NC 125V 22DB SOT262A1
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 18A |
| Current - Test | 100 mA |
| Power - Output | 300W |
| Voltage - Rated | 125 V |
| Voltage - Test | 50 V |
| AC and DC characteristics | |
| Frequency | 108MHz |
| Gain | 22dB |
| Noise Figure | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Package | Tray |
| Package / Case | SOT-262A1 |
| Supplier Device Package | CDFM4 |
| Other | |
| Mfr | Ampleon USA Inc. |
| Product Status | Obsolete |
| Series | - |
| Transistor Type | 2 N-Channel (Dual) Common Source |
Documents
No documents are linked to this part yet.
