Key specs
CircuitSPST
Current rating100 mAMax
| Power | |
|---|---|
| Current Rating (Amps) | 100mA |
| Voltage Rating | 5VDC |
| Environment and package | |
| Height Above Board | 0.380" (9.64mm) |
| Mounting Type | Through Hole, Right Angle |
| Operating Temperature | -40°C~85°C |
| Package | Tube |
| Other | |
| Actuator Level | Raised |
| Actuator Type | Slide (Standard) |
| Body Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Circuit | SPST |
| Contact Finish | Gold |
| Contact Material | Phosphor Bronze |
| Electrical Life | 10,000 Cycles |
| Features | - |
| Length | 0.980" (24.89mm) |
| Mechanical Life | 10,000 Cycles |
| Mfr | C&K |
| Number of Positions | 9 |
| Pitch | 0.100" (2.54mm), Full |
| Product Status | Active |
| Series | BD |
| Termination Style | PC Pin |
| Washable | Yes |
