ATS-HP-F6L70S68W-323
Advanced Thermal Solutions Inc.United States

ATS-HP-F6L70S68W-323

ActiveHeat Pipes, Vapor Chambers

FLAT HEATPIPE 68W 7.2X4.5X70MM

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Power - Cooling85.5W @ 70mm
Environment and package
Height0.177" (4.50mm)
Operating Temperature30°C~120°C
PackageBulk
Thermal Resistance-
Other
Attachment MethodEpoxy or Solder
Base Product NumberATS-HP-F6
Diameter-
Length2.756" (70.00mm)
MaterialCopper
MfrAdvanced Thermal Solutions Inc.
Minimum Bend Radius-
Platform-
Product StatusActive
Series-
ShapeFlat
TypeHeat Pipe
Wick TypeSintered
Width0.285" (7.23mm)
Working FluidDistilled Water
