Diodes IncorporatedUnited States
THERMOSTAT PROG ACTIVE LOW 16QFN
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 20mA |
| Current - Supply | 40µA, 55µA |
| Voltage - Supply | 2.7 V ~ 5.5 V |
| AC and DC characteristics | |
| Accuracy | - |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Package | Tape & Reel (TR) |
| Package / Case | 16-VFQFN Exposed Pad |
| Supplier Device Package | 16-QFN (3x3) |
| Switching Temperature | Programmable |
| Trip Temperature Threshold | Hot |
| Other | |
| Base Product Number | AP2602 |
| Features | Selectable Trigger Voltage, Selectable Trip Point |
| Mfr | Diodes Incorporated |
| Output | Active Low |
| Output Function | /OverTemp |
| Output Type | Open Drain |
| Product Status | Active |
| Selectable Hysteresis | No |
| Series | - |
Documents
No documents are linked to this part yet.
