View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.310A |
| Power (Watts) | 3.72 W |
| Voltage Range | 5 ~ 12.6VDC |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 41.5dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Size / Dimension | Square - 92mm L x 92mm H |
| Other | |
| Air Flow | 51.3 CFM (1.44m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Base Product Number | AFB0912 |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection, Speed Sensor (Tach) |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Delta Electronics |
| Packaging | Bulk |
| Part Status | Obsolete |
| RPM | 3300 RPM |
| Series | AFB |
| Static Pressure | 0.156 in H2O (38.8 Pa) |
| Termination | 3 Wire Leads |
| Weight | 0.154 lb (69.85 g) |
| Width | 15.00mm |
