View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.340A |
| Power (Watts) | 4.08 W |
| Voltage Range | 7 ~ 13.8VDC |
| Voltage - Rated | 12VDC |
| AC and DC characteristics | |
| Noise | 40.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 80mm L x 80mm H |
| Other | |
| Air Flow | 46.6 CFM (1.30m³/min) |
| Approval Agency | CE, CSA, UL, VDE |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Sensor |
| Ingress Protection | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Mfr | Delta Electronics |
| Packaging | Bulk |
| Part Status | Obsolete |
| RPM | 4000 RPM |
| Series | AFB |
| Static Pressure | 0.267 in H2O (66.5 Pa) |
| Termination | 3 Wire Leads |
| Weight | 0.176 lb (79.83 g) |
| Width | 25.40mm |
Documents
No documents are linked to this part yet.
