View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating | 15 Amps |
| Dielectric Withstanding Voltage | 1000 Volts |
| Environment and package | |
| Contact Size | 14 AWG |
| Mounting Feature | Cable Clamp |
| Mounting Type | Cord |
| REACH Compliant | Compliant |
| RoHS Compliant | Compliant |
| Other | |
| Brand | Switchcraft |
| Cable Opening | 0.3 in |
| Color | Nickel/Black |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Plating Type | Gold |
| Contact Resistance | 0.05 Ohms |
| Coupling Locking Style | Button Latch |
| Gender | Male |
| Handle Material | Zinc |
| Insert Material Type | Molded Thermoplastic |
| Insulation Resistance | 1000 MOhms |
| Locking | Locking |
| Number of Conductors | 3 |
| Operating Force | 7 lbs |
| Packaging Type | Bulk |
| Product Line | QG |
| Shielding | Shielded |
| Standard Connector Type | XLR |
| Termination Style | Solder Cup |
