Thomas Research ProductsUnited States
LED STAR 1W 2700K 12VAC
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Max | 150mA |
| Current - Test | 100mA |
| Lumens/Watt @ Current - Test | 53 lm/W |
| Voltage - Forward (Vf) (Typ) | 12VAC |
| Environment and package | |
| Height | 1.61mm |
| Luminous Flux @ Current/Temperature | 63lm(Typ) |
| Package | Bulk |
| Size / Dimension | 19.70mm Dia |
| Temperature - Test | 25°C |
| Other | |
| Base Product Number | - |
| CCT (K) | 2700K |
| Color | White, Warm |
| Configuration | Starboard |
| CRI (Color Rendering Index) | - |
| Features | - |
| Lens Type | Flat |
| Light Emitting Surface (LES) | - |
| Mfr | Thomas Research Products |
| Product Status | Obsolete |
| Series | - |
| Type | LED Engine |
| Viewing Angle | 120° |
| Wavelength | - |
Documents
No documents are linked to this part yet.
