Coto TechnologyUnited States
RELAY RF SPST-NO 250MA 5V
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Coil Current | 33.3 mA |
| Coil Power | - |
| Coil Voltage | 5VDC |
| Contact Rating (Current) | 250 mA |
| Must Operate Voltage | 3.8 VDC |
| Must Release Voltage | 0.4 VDC |
| Switching Voltage | 100VAC, 100VDC - Max |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -20°C~85°C |
| Package | Tube |
| Other | |
| Coil Resistance | 150 Ohms |
| Coil Type | Non Latching |
| Contact Form | SPST-NO (1 Form A) |
| Contact Material | - |
| Features | Magnetic Shield |
| Mfr | Coto Technology |
| Operate Time | 0.25 ms |
| Product Status | Obsolete |
| Release Time | 0.05 ms |
| Series | 9900 |
| Termination Style | Gull Wing |
