View full reportTechnical parameters
| Power | |
|---|---|
| Voltage | 300 V |
| Environment and package | |
| Operating Temperature | -20°C ~ 75°C |
| Other | |
| Cable Type | Multi-Pair |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP) |
| Conductor Material | Copper, Tinned |
| Conductor Strand | 7/30 |
| Features | - |
| Jacket Color | White |
| Jacket (Insulation) Diameter | 0.127" (3.23mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.0170" (0.432mm) |
| Length | 1000.0' (304.8m) |
| Mfr | Belden Inc. |
| Number of Conductors | 4 (2 Pair Twisted) |
| Packaging | Bulk |
| Part Status | Obsolete |
| Ratings | - |
| Series | - |
| Shield Coverage | 100% |
| Shield Material | Aluminum |
| Shield Type | Foil |
| Usage | - |
| Wire Gauge | 22 AWG |
