URS-Fuse-Link | NH1XL | aBat/aR | DC 1500V | 160A | knife contacts | without Microswitch | Sem.Cond.Prot. Fuse-Link | Square Dimension
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Rated current | 160A |
| Rated voltage | DC 1500 V |
| Environment and package | |
| Size | NH1XL |
| Other | |
| 3D file | 3D file |
| Characteristic | aBat/aR |
| Constructions | Gripping lugs |
| Contact | Contact knife |
| Indicator / Striker Pin | without Microswitch |
| Item number | 9044125.160 |
| Product group | Sem.Cond.Prot. Fuse-Link |
| Product subgroup | Square Dimension |
| Rated breaking capacity | 100kA DC 1500V |
| Standard IEC | IEC 60269-7 |
| Standard UL | UL 248-13 |
| Type | Fuse-Link |
| Web PDF | Web PDF |
