Cinch Connectivity Solutions SemflexUnited States
CABLE HP 160S 25 FT LENGTH
All alternatives
View full reportTechnical parameters
| AC and DC characteristics | |
|---|---|
| Impedance | 50 Ohms |
| Environment and package | |
| Operating Temperature | -65°C~200°C |
| Package | Box |
| Other | |
| Base Product Number | 88164 |
| Cable Group | HP160S |
| Cable Type | Coaxial |
| Conductor Material | Copper, Silver Coated |
| Conductor Strand | Solid |
| Dielectric Diameter | 0.106" (2.69mm) |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Features | - |
| Jacket Color | Blue |
| Jacket (Insulation) Diameter | 0.190" (4.83mm) |
| Jacket (Insulation) Material | Fluorinated Ethylene-Propylene (FEP), Polyurethane (PU) |
| Length | 25.0' (7.62m) |
| Mfr | Cinch Connectivity Solutions Semflex |
| Product Status | Active |
| Series | HP |
| Shield Coverage | - |
| Shield Material | Copper, Silver Coated |
| Shield Type | Foil, Braid |
| Usage | - |
| VoP, Velocity of Propagation | 76 |
| Wire Gauge | - |
Documents
No documents are linked to this part yet.
