CrouzetFrance
COUNTER LCD 8 CHAR 3V PANEL MT
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Voltage - Supply | Battery, 3VDC |
| Environment and package | |
| Display Characters - Height | 0.275" (7.00mm) |
| Mounting Type | Panel Mount |
| Operating Temperature | 0°C~55°C |
| Package | Bulk |
| Panel Cutout Dimensions | Rectangular - 44.80mm x 22.00mm |
| Other | |
| Count Rate | 7kHz |
| Display Type | LCD - Black Characters |
| Ingress Protection | IP66 - Dust Tight, Water Resistant |
| Input Type | No Voltage, Voltage |
| Mfr | Crouzet |
| Number of Characters Per Row | 8 |
| Operating Mode | Up |
| Output Type | - |
| Product Status | Obsolete |
| Reset | External, Front Panel |
| Series | CP2 2108 |
| Termination Style | Screw Terminal |
| Time Format | - |
| Type | Totalizer |
| Weight | 0.132 lb (59.87 g) |
Documents
No documents are linked to this part yet.
