83-875-1002
AmphenolUnited States

83-875-1002

ActiveCoaxial Connector (RF) Assemblies

CONN UHF RCPT STR 50 OHM SOLDER

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Key specs

GenderFemale
Impedance50 Ω
Max frequency300 MHzMax
Power
Voltage Rating500 V
AC and DC characteristics
Frequency - Max300 MHz
Impedance50Ohm
Environment and package
Mounting FeatureBulkhead - Rear Side Nut
Mounting TypePanel Mount
Operating Temperature-
PackageBulk
Other
Base Product Number83-8
Body FinishNickel
Body MaterialBrass
Cable Group-
Center Contact MaterialBrass
Center Contact PlatingSilver
Connector StyleUHF
Connector TypeReceptacle, Female Socket
Contact TerminationSolder Cup
Dielectric MaterialPolytetrafluoroethylene (PTFE)
Fastening TypeThreaded
Features-
Housing ColorSilver
Includes3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Ingress Protection-
Insertion Loss-
Mating Cycles500
MfrAmphenol RF
Number of Ports1
Product StatusActive
Series-
Shield TerminationSolder
