Coto TechnologyUnited States
RELAY REED SPDT 250MA 12V
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Coil Current | 24 mA |
| Coil Voltage | 12VDC |
| Contact Rating (Current) | 250 mA |
| Must Operate Voltage | 9.6 VDC |
| Must Release Voltage | 1 VDC |
| Switching Voltage | 100VAC, 100VDC - Max |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -20°C~85°C |
| Package | Tube |
| Other | |
| Coil Resistance | 500 Ohms |
| Coil Type | Non Latching |
| Contact Form | SPDT (1 Form C) |
| Contact Material | - |
| Features | - |
| Mfr | Coto Technology |
| Operate Time | 1 ms |
| Product Status | Obsolete |
| Release Time | 1 ms |
| Seal Rating | - |
| Series | 8000 |
| Termination Style | J Lead |
Documents
No documents are linked to this part yet.
