IskraSlovenia
KNB1560 U15 10% 275V L9.6 R15
All alternatives
View full reportTechnical parameters
Key specs
Capacitance150 nF
Rated voltage630 V
Tolerance10 %
| Power | |
|---|---|
| Voltage Rating - AC | 275V |
| Voltage Rating - DC | 630V |
| Environment and package | |
| Height - Seated (Max) | 0.276" (7.00mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~110°C |
| Package | Bulk |
| Package / Case | Radial |
| Other | |
| Applications | General Purpose |
| Capacitance | 0.15 µF |
| Dielectric Material | Polypropylene (PP), Metallized |
| Lead Spacing | 0.591" (15.00mm) |
| Mfr | Iskra |
| Product Status | Active |
| Series | KNB1560 |
| Termination | PC Pins |
| Tolerance | ±10% |
