View full reportTechnical parameters
Key specs
Reverse voltage1 kV
Average rectified current6 A
Forward voltage1 VMax · 6 A
TypeStandardStandard Recovery >500ns，> 200mA (Io)
| Power | |
|---|---|
| Current - Average Rectified (Io) | 6A |
| Current - Reverse Leakage @ Vr | 300 nA @ 1000 V |
| Voltage - DC Reverse (Vr) (Max) | 1000 V |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 6 A |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Package / Case | R-6, Axial |
| Supplier Device Package | R-6 |
| Other | |
| Capacitance @ Vr, F | 150pF @ 4V, 1MHz |
| Mfr | Rectron USA |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Series | - |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
