626
ActiveCTS Model 626 is a low cost, high performance clock oscillator supporting differential LVPECL or LVDS outputs. Employing the latest IC technology, M626 has excellent stability and very low jitter/phase noise performance. Download the CTS components are stocked and sold through a global network of distributors & sales representatives. Select your preferred partner in the link below.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Voltage (V) | 1.8V / 2.5V / 3.3V |
| AC and DC characteristics | |
| Frequency Range (MHz) | 6 - 220 |
| Frequency Stability (PPM) | ±20 / ±25 / ±30 / ±50 |
| Environment and package | |
| Package (mm) | 2.5 x 2.0 SMD |
| Temperature Range (C) | -20°–70° / -40°–105° / -40°–85° |
| Other | |
| Output | LVDS / LVPECL |
| Phase Jitter (fs typ) | 500 |
