View full reportTechnical parameters
| Environment and package | |
|---|---|
| Fin Height | 0.250" (6.35mm) |
| Package | Bulk |
| Package Cooled | BGA |
| Power Dissipation @ Temperature Rise | - |
| Thermal Resistance @ Forced Air Flow | 25.00°C/W @ 200 LFM |
| Thermal Resistance @ Natural | - |
| Other | |
| Attachment Method | Thermal Tape, Adhesive (Included) |
| Base Product Number | 624-25 |
| Diameter | - |
| Length | 0.827" (21.00mm) |
| Material | Aluminum |
| Material Finish | Black Anodized |
| Mfr | Wakefield-Vette |
| Product Status | Active |
| Series | 624 |
| Shape | Square, Pin Fins |
| Type | Top Mount |
| Width | 0.827" (21.00mm) |
Documents
No documents are linked to this part yet.
