Switchcraft Inc.United States
Nanomizer M8 Cable Assemblies, Receptacle with Leads, 4 Position, Female Sockets, 0.3 Meter Length
All alternatives
View full reportTechnical parameters
Key specs
GenderFemale
| Power | |
|---|---|
| Current Rating | 4 Amps |
| Voltage Rating | 300 Volts |
| Environment and package | |
| Conductor Size | 24 AWG |
| Contact Size | 24 AWG |
| Maxiumum Temperature | 105 C |
| Minimum Temperature | -20 C |
| Mounting Feature | Lock Ring |
| Mounting Type | Receptacle with Leads |
| REACH Compliant | Compliant |
| RoHS Compliant | Compliant |
| Temperature Range | -25C to +105C |
| Wire Size | 24 AWG |
| Other | |
| Body Material | PVC |
| Body Plating | Nickel |
| Brand | Conxall |
| Cable Color | Yellow |
| Color | Yellow |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Plating Type | Gold |
| Coupling Locking Style | Threaded |
| CSA | 1 |
| Gender | Female |
| Insert Material | Glass Filled Nylon |
| IP65 | 1 |
| IP66 | 1 |
| IP67 | 1 |
| IP68 | 1 |
| IP Rating | IP68 |
| Length | 0.3 in |
| Locking | Locking |
| Number of Conductors | 4 |
| O-Ring Material | Viton |
| Packaging Type | Bulk |
| Product Line | SensorLink |
| Sealed | Sealed |
| Shielding | Unshielded |
| Standard Connector Type | M8 |
| Termination Style | Leadwires |
| UL | 1 |
