Skyworks Solutions Inc.United States
XTAL OSC VCXO 148.5000MHZ LVDS
All alternatives
View full reportTechnical parameters
Key specs
Frequency148.5 MHz
Frequency stability20 ppm
Supply voltage≥ 3.3 V
Output typeLVDS
| Power | |
|---|---|
| Current - Supply (Max) | 110mA |
| Voltage - Supply | 3.3V |
| AC and DC characteristics | |
| Frequency | 148.5 MHz |
| Frequency Stability | ±20ppm |
| Spread Spectrum Bandwidth | - |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C |
| Package | Strip |
| Package / Case | 8-SMD, No Lead |
| Size / Dimension | 0.276" L x 0.197" W (7.00mm x 5.00mm) |
| Other | |
| Absolute Pull Range (APR) | ±100ppm |
| Base Product Number | 599BDB |
| Base Resonator | Crystal |
| Function | Enable/Disable (Reprogrammable) |
| Mfr | Skyworks Solutions Inc. |
| Output | LVDS |
| Product Status | Active |
| Ratings | - |
| Series | Si599 |
| Type | VCXO |
Documents
No documents are linked to this part yet.
