Bourns Inc.United States
FIXED IND 900UH 3.75A 175MOHM TH
All alternatives
View full reportTechnical parameters
Key specs
Inductance900 µH
Rated current3.75 AMax
DC resistance175 mΩMax
| Power | |
|---|---|
| Current Rating (Amps) | 3.75 A |
| Current - Saturation (Isat) | - |
| AC and DC characteristics | |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 1 kHz |
| Environment and package | |
| Height - Seated (Max) | - |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C~105°C |
| Package | Bulk |
| Package / Case | Radial, Vertical (Open) |
| Size / Dimension | 2.125" Dia x 0.937" W (53.97mm x 23.80mm) |
| Supplier Device Package | - |
| Other | |
| Base Product Number | 5722 |
| DC Resistance (DCR) | 175mOhm Max |
| Inductance | 900 µH |
| Material - Core | Iron Powder |
| Mfr | Bourns Inc. |
| Product Status | Active |
| Q @ Freq | - |
| Ratings | - |
| Series | 5700 |
| Shielding | Unshielded |
| Tolerance | ±15% |
| Type | Toroidal |
