5640300111F
DialightUnited Kingdom

5640300111F

ActiveLEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs

LED 3HI 3MM 5V RED PC MNT

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current10mA
Voltage Rating5V
Environment and package
Mounting TypeThrough Hole, Right Angle
PackageBulk
Other
Base Product Number5640300
ColorRed (x 3)
Configuration3 High
Lens TypeDiffused, Tinted
MfrDialight
Millicandela Rating29mcd
Product StatusActive
Series564
Viewing Angle60°
Wavelength - Peak635nm

Documents

No documents are linked to this part yet.
