5553301
DialightUnited Kingdom

5553301

ObsoleteLEDs - Circuit Board Indicators, Arrays, Light Bars, Bar Graphs

LED 2MM VERTICAL GREEN PC MNT

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Power
Current20mA
Voltage Rating2.4V
Environment and package
Lens Size2.00mm Dia
Mounting TypeThrough Hole
PackageBulk
Other
ColorGreen
ConfigurationSingle
Lens StyleRound with Domed Top
Lens TypeClear
MfrDialight
Millicandela Rating1mcd
Product StatusObsolete
Series555
Viewing Angle40°
Wavelength - Peak565nm

Documents

No documents are linked to this part yet.
