NFC-Fuse-Link | 14x51 | aM | AC 690V | 1A | without indicator | LV-Fuse-Link | French Standard cylindrical
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Rated current | 1A |
| Rated voltage | 690 V |
| Environment and package | |
| Dimensions | 14x51 |
| Other | |
| 3D file | 3D file |
| Characteristic | aM |
| Item number | 5005807.1 |
| Product group | LV-Fuse-Link |
| Product subgroup | French Standard cylindrical |
| Rated breaking capacity | 100kA AC 690V |
| Standard IEC | IEC 60269-2 |
| Type | Fuse-Link |
