View full reportTechnical parameters
| Power | |
|---|---|
| Maximum charge power | 3.5KW |
| Power contact rated voltage | 240 |
| Power pin quantity | 3 |
| Rated Current | / / / / 65A |
| Rated current of high-power contacts | 65A |
| Rated Voltage | / / / / 240V |
| Signal contact rated current | 2 |
| Signal contact rated voltage | 30 |
| Environment and package | |
| Ambient temperature (operation) | -30 °C ~ 50 °C |
| Ambient temperature (storage/transportation) | -40°C ~ +80°C |
| Environmental items(Compliant with REACH/RoHS ) | Yes |
| Other | |
| Cable composition | 2*8AWG+1*10AWG+4*22AWG |
| Cable length | 5000±100mm |
| Cable outer diameter | 15.0±0.5mm |
| Certification | UL |
| Contact surface material | Ag |
| Cover color | black |
| Customization basis | Provided according to customer requirements |
| Flammability rating | V0 |
| Handle material area | Plastic |
| Insertion force | <90N |
| Insertion/pullout cycle | 10000 |
| IP class | Type 3S |
| Minimum bend radius | 90mm |
| Minimum order quantity | 5 |
| MTAC-S-065A-V5-03-5.0M-10A(H).pdf | Download |
| MTAC-S-065A-V5-03-5.0M-10A(H).stp | Download |
| Order number | 22030000353 |
| Outer sheath,color | black |
| Outer sheath, material | TPE |
| Packing unit | 5 |
| Phase | 1 |
| Protective cover material | Soft plastic |
| Pull out force | <90N |
| Quantity of signal contacts | 2 |
| Shell color | black |
| Shell material | Plastic |
| Signal transmission type | Pulse width adjustment |
| Strip length | 100±10mm |
| Vehicle connector depth | 194.3mm（Vehicle charging connector） |
| Vehicle connector width | 41.5mm（Vehicle charging connector） |
| Wire type | Straight line |
| Wiring level | 5 class |
| Wiring standard | UL62 |
