356-V3-156-00-014101
Preci-DipSwitzerland

356-V3-156-00-014101

ActiveHeaders, Male Pins

CONN HEADER VERT 56POS 2.54MM

See alternativesAsk AI FAE

All alternatives

View full report

Technical parameters

Key specs

Positions56
Rows1
Pitch2.54 mm
GenderMale
Current rating3 AMax
Power
Current Rating (Amps)3A
Voltage Rating150VDC
Environment and package
Insulation Height0.116" (2.95mm)
Mated Stacking Heights-
Mounting TypeThrough Hole
Operating Temperature-55°C~125°C
PackageBulk
Other
Applications-
Base Product Number356-V3
Connector TypeHeader
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thickness - Mating29.5µin (0.75µm)
Contact Finish Thickness - Post-
Contact Length - Mating0.141" (3.60mm)
Contact Length - Post0.110" (2.79mm)
Contact MaterialBronze
Contact ShapeCircular
Contact TypeMale Pin
Fastening TypePush-Pull
Features-
Ingress Protection-
Insulation ColorBlack
Insulation MaterialPolycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Material Flammability RatingUL94 V-0
MfrPreci-Dip
Number of Positions56
Number of Positions LoadedAll
Number of Rows1
Overall Contact Length0.378" (9.60mm)
Pitch - Mating0.100" (2.54mm)
Product StatusActive
Row Spacing - Mating-
Series356
ShroudingUnshrouded
StyleBoard to Board
TerminationPress-Fit, Solder

Documents

No documents are linked to this part yet.
