Mill-Max Manufacturing Corp.United States
CONN SOCKET SIP 35POS GOLD
All alternatives
View full reportTechnical parameters
Key specs
Pitch2.54 mm
Current rating3 AMax
| Power | |
|---|---|
| Current Rating (Amps) | 3 A |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C~125°C |
| Package | Bulk |
| Other | |
| Base Product Number | 346-93 |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin-Lead |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Material - Mating | Beryllium Copper |
| Contact Material - Post | Brass Alloy |
| Contact Resistance | - |
| Features | - |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester |
| Material Flammability Rating | - |
| Mfr | Mill-Max Manufacturing Corp. |
| Number of Positions or Pins (Grid) | 35 (1 x 35) |
| Pitch - Mating | 0.100" (2.54mm) |
| Pitch - Post | 0.100" (2.54mm) |
| Product Status | Active |
| Series | 346 |
| Termination | Press-Fit |
| Termination Post Length | 0.175" (4.45mm) |
| Type | SIP |
