View full reportTechnical parameters
| Environment and package | |
|---|---|
| Mounting Type | Free Hanging (In-Line) |
| Package | Bulk |
| Stud/Tab Size | - |
| Other | |
| Base Product Number | 3256 |
| Color | - |
| Contact Finish | Tin |
| Contact Material | Copper |
| Diameter - Barrel ID | 0.648" (16.46mm) |
| Diameter - Barrel OD | 0.802" (20.37mm) |
| Diameter - Ring ID | - |
| Features | - |
| Insulation | Non-Insulated |
| Length - Overall | 4.210" (106.93mm) |
| Mfr | TE Connectivity AMP Connectors |
| Product Status | Discontinued at Digi-Key |
| Series | Ampower |
| Tab Thickness | 0.130" (3.30mm) |
| Terminal Style | No Stud Hole |
| Terminal Type | Standard |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.190" (30.23mm) |
| Wire Gauge | 4/0 AWG |
Documents
No documents are linked to this part yet.
